Patents Examined by David H. Malzahn

Patent number: 10713011Abstract: Examples of the present disclosure provide apparatuses and methods for performing multiplication operations in a memory. An example method comprises performing a multiplication operation on a first element stored in a group of memory cells coupled to a first access line and a number of sense lines of a memory array and a second element stored in a group of memory cells coupled to a second access line and the number of sense lines of the memory array. The method can include a number operations performed without transferring data via an input/output (I/O) line.Type: GrantFiled: September 9, 2019Date of Patent: July 14, 2020Assignee: Micron Technology, Inc.Inventor: Sanjay Tiwari

Patent number: 10705799Abstract: An optical system uses a multilayered birefringent structure that receives an input beam that may be noncoherent or coherent, and produces a randomization energy from the input beam, by creating birefringent induced beam subdivisions as the beam passes through each birefringent layer, where after the beam has passed through a threshold number of birefringent layers, a randomized energy distribution is created. That randomized energy distribution is read by a photodetector and converted into a random number by a randomization processing device.Type: GrantFiled: August 26, 2019Date of Patent: July 7, 2020Inventor: Carol Y. Scarlett

Patent number: 10705798Abstract: Examples of the present disclosure provide apparatuses and methods for performing multivariable bitlength multiplication operations in a memory. An example method comprises performing a multiplication operation on a first vector and a second vector. The first vector includes a number of first elements stored in a group of memory cells coupled to a first access line and a number of sense lines of a memory array. The second vector includes a number of second elements stored in a group of memory cells coupled to a second access line and the number of sense lines of the memory array. The example multiplication operation can include performing a number of AND operations, OR operations and SHIFT operations without transferring data via an input/output (I/O) line.Type: GrantFiled: September 6, 2019Date of Patent: July 7, 2020Assignee: Micron Technology, Inc.Inventor: Sanjay Tiwari

Patent number: 10698655Abstract: Hardware logic arranged to normalise (or renormalise) an nbit input number is described in which at least a proportion of a left shifting operation is performed in parallel with a leading zero count operation. In various embodiments the left shifting and the leading zero count are performed independently. In various other embodiments, a subset of the bits output by a leading zero counter are input to a left shifter and the output from the left shifter is input to a renormalisation block which completes the remainder of the left shifting operation independently of any further input from the leading zero counter.Type: GrantFiled: January 18, 2019Date of Patent: June 30, 2020Assignee: Imagination Technologies LimitedInventor: Theo Alan Drane

Patent number: 10691772Abstract: A method includes storing a sparse triangular matrix as a compressed sparse row (CSR) dataset. For each factor of a plurality of factors in a first vector, a value of the factor is calculated by identifying for the factor a set of one or more antecedent factors in the first vector, where the value of the factor is dependent on each of the one or more antecedent factors. In response to a completion array indicating that all of the one or more antecedent factor values are solved, the value of the factor is calculated based on one or more elements in a row of the matrix and a product value corresponding to the row. In the completion array, a first completion flag for the factor is asserted, indicating that the factor is solved.Type: GrantFiled: April 20, 2018Date of Patent: June 23, 2020Assignee: Advanced Micro Devices, Inc.Inventor: Joseph Lee Greathouse

Patent number: 10685421Abstract: Embodiments relate to a configurable convolution engine that receives configuration information to perform convolution and other deep machine learning operations on streaming input data of various formats. The convolution engine may include two convolution circuits that each generate a stream of values by applying convolution kernels to input data. The stream of values may each define one or more channels of image data. A channel merge circuit combines the streams of values from each convolution circuit in accordance with a selected mode of operation. In one mode, the first and second streams from the convolution circuits are merged into an output stream having the combined channels of the first and second streams in an interleaved manner. In another mode, the first stream from the first convolution circuit is fed into the input of the second convolution circuit.Type: GrantFiled: October 25, 2019Date of Patent: June 16, 2020Assignee: Apple Inc.Inventors: Sung Hee Park, Muge Wang, Junji Sugisawa

Patent number: 10684982Abstract: A print controller includes a processor and a memory. When an instruction to execute a specific calculation function is received, the processor obtains a calculation result related to the specific calculation function. When an instruction to print is received, if the instruction to execute the specific calculation function has been received a plurality of times without printing the calculation result related to the specific calculation function, which was obtained when the instruction to execute the calculation function was received one or more times before the instruction received at a last time of the plurality of times, the processor causes a printing device to print the calculation result related to the specific calculation function, which was obtained when the instruction to execute the specific calculation function was received at the last time of the plurality of times.Type: GrantFiled: October 3, 2019Date of Patent: June 16, 2020Assignee: CASIO COMPUTER CO., LTD.Inventors: Hiroaki Yoshizawa, Hironori Yoshikawa

Patent number: 10673662Abstract: A method for generating M parallel pseudorandom binary sequences (PRBSs), each comprising a 2n?1 sequence of pseudorandom bits, includes loading into the circuit an initial Mbit word, the initial Mbit word comprising M sequential bits selected from a predetermined PRBSn sequence, wherein n>1 and M>n. The method includes generating, using a plurality of logic gates of the circuit, a next Mbit word using at least n+1 of the M sequential bits of the initial Mbit word. The method includes repeatedly generating, using the logic gates of the circuit, the next Mbit word from a previous Mbit word using the at least n+1 of M sequential bits of the previous Mbit word, resulting in M parallel sequences of the PRBSn sequence. The method includes transmitting the generated next Mbit words on an Mbit wide parallel bus.Type: GrantFiled: May 11, 2018Date of Patent: June 2, 2020Assignee: KEYSIGHT TECHNOLOGIES, INC.Inventor: Colin Johnstone

Patent number: 10656913Abstract: Techniques for operating on and calculating binary floatingpoint numbers using an enhanced floatingpoint number format are presented. The enhanced format can comprise a single sign bit, six bits for the exponent, and nine bits for the fraction. Using six bits for the exponent can provide an enhanced exponent range that facilitates desirably fast convergence of computingintensive algorithms and low error rates for computingintensive applications. The enhanced format can employ a specified definition for the lowest binade that enables the lowest binade to be used for zero and normal numbers; and a specified definition for the highest binade that enables it to be structured to have one data point used for a merged NotaNumber (NaN)/infinity symbol and remaining data points used for finite numbers. The signs of zero and merged NaN/infinity can be “don't care” terms. The enhanced format employs only one rounding mode, which is for rounding toward nearest up.Type: GrantFiled: June 5, 2018Date of Patent: May 19, 2020Assignee: INTERNATIONAL BUSINESS MACHINES CORPORATIONInventors: Silvia Melitta Mueller, Ankur Agrawal, Bruce Fleischer, Kailash Gopalakrishnan, Dongsoo Lee

Patent number: 10656942Abstract: Embodiments of instructions and methods of execution of said instructions and resources to execute said instructions are detailed. For example, in an embodiment, a processor comprising: decode circuitry to decode an instruction having fields for an opcode, a packed data source operand identifier, and a packed data destination operand identifier; and execution circuitry to execute the decoded instruction to convert a data element from a least significant packed data element position of the identified packed data source operand from a fixedpoint representation to a floating point representation, store the floating point representation into a 32bit least significant packed data element position of the identified packed data destination operand, and zero all remaining packed data elements of the identified packed data destination operand is described.Type: GrantFiled: March 4, 2019Date of Patent: May 19, 2020Assignee: Intel CorporationInventors: Venkateswara Madduri, Elmoustapha OuldAhmedVall, Robert Valentine, Jesus Corbal, Mark Charney

Patent number: 10649731Abstract: Integrated circuits with specialized processing blocks are provided. A specialized processing block may include one real addition stage and one real multiplier stage. The multiplier stage may simultaneously feed its output to the addition stage and directly to an adjacent specialized processing block. The addition stage may also produce sum and difference outputs in parallel. A group of four such specialized processing blocks may be connected in a chain to implement a radix2 fast Fourier transform (FFT) butterfly. Multiple radix2 butterflies may be stacked to form yet higher order radix butterflies. If desired, the specialized processing block may also be used to implement a complex multiply operation. Three or four specialized processing blocks may be chained together and along with one or more adders outside the specialized processing blocks, real and imaginary portions of a complex product can be generated.Type: GrantFiled: October 23, 2018Date of Patent: May 12, 2020Assignee: Altera CorporationInventor: Martin Langhammer

Patent number: 10642578Abstract: A binary logic circuit for approximating a mathematical function over a predefined range as a series of linear segments, each linear segment having one of a predetermined set of fixed gradients and a corresponding base value, the binary logic circuit comprising: an input for receiving an input variable in the predefined range; a plurality of logic chains each comprising: a binary multiplier adapted to perform multiplication by a respective one of the set of fixed gradients using h?1 binary adders, where h is the extended Hamming weight; and a binary adder adapted to add a base value to the input or output of the binary multiplier; and selection logic configured to select one of the logic chains in dependence on the input variable so as to provide, for the received input variable, an approximate value of the mathematical function.Type: GrantFiled: July 23, 2019Date of Patent: May 5, 2020Assignee: Imagination Technologies LimitedInventor: Tim Lee

Patent number: 10635396Abstract: A multiplier circuit includes a partial product generation circuit, a truncation circuit, and a summation circuit. The partial product generation circuit is configured to generate a plurality of partial products for multiplying two values. The truncation circuit is coupled to the partial product generation circuit. The truncation circuit is configured to shorten at least some of the partial products by removing a least significant bit from the at least some of the partial products. The summation circuit coupled to the truncation circuit. The summation circuit is configured to sum the truncated partial products produced by the truncation circuit.Type: GrantFiled: June 27, 2019Date of Patent: April 28, 2020Assignee: TEXAS INSTRUMENTS INCORPORATEDInventors: Jawaharlal Tangudu, Suvam Nandi, Pooja Sundar, Jaiganesh Balakrishnan

Patent number: 10635740Abstract: Methods, systems, and apparatus for a matrix multiply unit implemented as a systolic array of cells are disclosed. The matrix multiply unit may include cells arranged in columns of the systolic array. Two chains of weight shift registers per column of the systolic array are in the matrix multiply unit. Each weight shift register is connected to only one chain and each cell is connected to only one weight shift register. A weight matrix register per cell is configured to store a weight input received from a weight shift register. A multiply unit is coupled to the weight matrix register and configured to multiply the weight input of the weight matrix register with a vector data input in order to obtain a multiplication result.Type: GrantFiled: May 17, 2018Date of Patent: April 28, 2020Assignee: Google LLCInventors: Andrew Everett Phelps, Norman Paul Jouppi

Patent number: 10613833Abstract: The present relates to invention deals with an execution unit configured to execute a computer program instruction to generate random numbers based on a predetermined probability distribution. The execution unit comprises a hardware pseudorandom number generator configured to generate at least randomised bit string on execution of the instruction and adding circuitry which is configured to receive a number of bit sequences of a predetermined bit length selected from the randomised bit string and to sum them to produce a result.Type: GrantFiled: February 1, 2018Date of Patent: April 7, 2020Assignee: Graphcore LimitedInventors: Stephen Felix, Godfrey Da Costa

Patent number: 10613829Abstract: A full adder is provided in which a sum logic circuit for producing the sum signal and a carryout logic circuit for producing the carryout output paths do not share internal nodes. In addition, the sum logic circuit and the carryout logic circuit are both configured to obviate the need for transmission gates with respect to forming the sum signal and the carryout signal.Type: GrantFiled: May 17, 2018Date of Patent: April 7, 2020Assignee: QUALCOMM IncorporatedInventors: Manish Srivastava, Esakkimuthu Dhakshinamoorthy, Neha Gupta

Patent number: 10606560Abstract: Deterministic asymmetry in a random number generator can be mitigated by a circuit that includes a first inverter, a second inverter, a first capacitor, a second capacitor, a first switch, and a second switch. The first inverter can include a first input terminal and a first output terminal. The first inverter can have a first inverter threshold voltage. The second inverter can include a second input terminal and a second output terminal. The second inverter can have a second inverter threshold voltage. The first capacitor can be conductively coupled between the first output terminal and the second output terminal. The second capacitor can be conductively coupled between the second output terminal and the first input terminal. The first switch can be conductively coupled between the first input terminal and the first output terminal. The second switch can be conductively coupled between the second input terminal and the second output terminal.Type: GrantFiled: May 9, 2018Date of Patent: March 31, 2020Assignee: VERILY LIFE SCIENCES LLCInventors: Nathan Pletcher, Robert Wiser, Alireza Dastgheib

Patent number: 10599608Abstract: A calculator includes: a plurality of numeric keys; a plurality of operation keys; a delimiter key; a memory; and a processor, wherein said processor is configured to: when a first numerical data having at least a first integer, a delimiter, and a second integer arranged in that order has been received, upon receiving a prescribed operation of one of said plurality of operation keys, registers said first integer in said memory as a first operand, and registers said second integer in said memory as a second operand; and registers in said memory a targetoperand that has been inputted via an operation or operations of at least one of said plurality of numeric keys, and performs a prescribed arithmetic operation on said targetoperand registered in said memory using a plurality of registered operands that include the registered first and second operands.Type: GrantFiled: January 18, 2018Date of Patent: March 24, 2020Assignee: CASIO COMPUTER CO., LTD.Inventors: Hironori Yoshikawa, Hiroaki Yoshizawa

Patent number: 10579936Abstract: Embodiments of quantum ring oscillatorbased coherence preservation circuits including a cascaded set of stages are described. Embodiments of such quantum ring oscillatorbased coherence preservation circuits allow the internal (superpositioned) quantum state information of stored qubits to be preserved over long periods of time and present options for the measurement and potential correction of both deterministic and nondeterministic errors without disturbing the quantum information stored in the structure itself.Type: GrantFiled: April 27, 2018Date of Patent: March 3, 2020Assignee: BRAKET SCIENCE, INC.Inventors: Mitchell A Thornton, Duncan L. MacFarlane, Timothy P. LaFave, Jr., William V. Oxford

Patent number: 10579334Abstract: A system for block floating point computation in a neural network receives a plurality of floating point numbers. An exponent value for an exponent portion of each floating point number of the plurality of floating point numbers is identified and mantissa portions of the floating point numbers are grouped. A shared exponent value of the grouped mantissa portions is selected according to the identified exponent values and then removed from the grouped mantissa portions to define multitiered shared exponent block floating point numbers. One or more dot product operations are performed on the grouped mantissa portions of the multitiered shared exponent block floating point numbers to obtain individual results. The individual results are shifted to generate a final dot product value, which is used to implement the neural network. The shared exponent block floating point computations reduce processing time with less reduction in system accuracy.Type: GrantFiled: May 8, 2018Date of Patent: March 3, 2020Assignee: Microsoft Technology Licensing, LLCInventors: Daniel Lo, Eric Sen Chung
