7.3. Other Popular Controllers 261

×

Im(z)

Re(z)

Figure 7.17: Pole–zero location of the integral mode

Taking the Z-transform of both sides, we obtain

Y (z) = z−1Y (z) +

Ts

2

[

U(z) + z−1U(z)

]

Simplifying this, we obtain

Y (z) =

Ts

2

1 + z−1

1− z−1U(z) (7.38)

If we denote the transfer function of the integrator by Gi, we see that it is given by

Gi(z) =

Ts

2

z + 1

z − 1 . (7.39)

This is known as the trapezoidal approximation or Tustin approximation or bilinear

approximation. The transfer function Gi is low pass as it has a pole at ω = 0 and a

zero at ω = π, see Fig. 7.17. Thus we see that integration, a smoothing operation, is

low pass. We explain the role of the integral mode with an example.

Example 7.4 Evaluate the effect of an integrating controller

Gi(z) =

z + 1

z − 1

when used with a nonoscillating plant given by

G(z) =

z

z − a

where a > 0. The closed loop transfer function becomes

T (z) =

z

z−a

z+1

z−1

1 + z

z−a

z+1

z−1

=

z(z + 1)

2z2 − az + a

The poles are at (a ±

√

a2 − 8a)/4. For all a < 8, the closed loop system is

oscillatory. When a PI controller of the following form is used

Gc(z) = K

(

1 +

1

τi

z + 1

z − 1

)

Page 278

262 7. Structures and Specifications

the overall transfer function becomes

T (z) =

K

(

1 + 1

τi

z+1

z−1

)

z

z−a

1 +K

(

1 + 1

τi

z+1

z−1

)

z

z−a

The steady state output for a step input is given by limn→∞ y(n), which is equal

to limz→1 T (z) = 1, see Eq. 4.21 on page 83. This shows that there is no steady

state offset.

Because the reciprocal of integration is differentiation, we obtain the transfer

function of discrete time differentiation Gd as the reciprocal of Gi, given in Eq. 7.39.

We obtain

Gd(z) =

1

Gi(z)

=

2

Ts

z − 1

z + 1

(7.40)

This form, however, has a problem: Gd(z) has a pole at z = −1 and hence it produces,

in partial fraction expansion, a term of the form

z

z + 1

↔ (−1)n (7.41)

which results in a wildly oscillating control effort, see Sec. 5.1.1. Because of this,

we consider other ways of calculating the area given in Fig. 7.16. For example, we

approximate the area under the curve with the following backward difference formula:

y(k) = y(k − 1) + Tsu(k) (7.42)

Taking the Z-transform and simplifying it, we obtain

Y (z) = Ts

z

z − 1U(z)

We arrive at the following transfer functions of the integrator and differentiator as

Gi(z) = Ts

z

z − 1

Gd(z) =

1

Ts

z − 1

z

(7.43)

It is also possible to use the forward difference approximation for integration

y(k) = y(k − 1) + Tsu(k − 1) (7.44)

This results in the following transfer functions of the integrator and differentiator as

Gi(z) =

Ts

z − 1

Gd(z) =

z − 1

Ts

(7.45)
