Tardigrades or Water Bears: Strange Animals and Impressive Facts

Linda Crampton is a writer and teacher with an honors degree in biology. She loves to study nature and write about living things.

A lateral or side view of a tardigrade as seen under a light microscope

A lateral or side view of a tardigrade as seen under a light microscope

Surprising and Impressive Animals

Tardigrades are resilient and very impressive animals. They are also known as water bears and as moss piglets. They survive in a range of extreme environmental conditions that would kill most other organisms, including very high and low temperatures, strong radiation, intense pressure, a vacuum, and dehydration. The animals are still surprising us. Studying their biology is fascinating and might be helpful for humans.

Tardigrades are tiny creatures but are visible to the unaided eye in suitable lighting conditions. At the moment, around 1,300 species are known. More may exist. In nature, the animals are found in fresh or salt water and in areas that tend to hold moisture on land. These areas include places with moss, lichens, leaf litter, or soil. The animals can survive in an inactive form if their environment dries up. They are widespread and can be found in many countries.

An Interesting Invertebrate

Tardigrades are invertebrates and belong to the phylum Tardigrada. The phylum contains two classes: Eutardigrada and Heterotardigrada. The members of the first class generally have a smooth outer covering, or cuticle, and the members of the second class have an armored one containing plates. The scanning electron micrograph below shows the plates of one species. The cuticle is shed and replaced as the animal grows.

Despite their small size, the animals contain organs and structures associated with other invertebrates. Though a tardigrade may be visible without a microscope, the instrument is needed in order to see details of the animal’s body. It's a multicellular creature that is sometimes referred to as a "micro-animal."

They (tardigrades) were first named tardigrada in Italian from the Latin meaning “slow walker.”

— William Randoph Miller, via American Scientist

Physical Appearance of a Tardigrade

One point that may puzzle some people is why a tardigrade looks translucent or transparent in real life or under a light microscope but opaque under a scanning electron microscope. The difference is due to the nature of the magnifying devices.

The tardigrade's body transmits light shone on it, so it looks transparent under a compound or light microscope. When a scanning electron microscope (SEM) is used, a concentrated beam of electrons is directed at the animal in a vacuum. The microscope scans the surface of the specimen with the electrons. The particles are not transmitted through the animal's body, though they penetrate a very short distance into it. The specimen is coated with a thin layer of metallic material to improve the conductivity of the electrons and get a better picture. The scene appears in shades of grey, but sometimes the photos taken by the microscope are colorized.

A scanning electron microscope can be a wonderful device for showing details of an animal's surface, as in the photo below. It doesn't show the animal as we would see it, however. Unfortunately, many illustrations of tardigrades show a picture resembling the opaque SEM view without indicating that the appearance of the animal is due to a particular investigative technique.

A scanning electron micrograph of a female armored tardigrade named Echiniscus succineus

A scanning electron micrograph of a female armored tardigrade named Echiniscus succineus

The photo above shows Echiniscus succineus and originated in New Echiniscidae (Heterotardigrada) from Amber Mountain (Northern Madagascar). Evolutionary Systematics 3(1): 29-39

External Features of the Animal

Scientists are discovering that the external and internal body features are similar but not completely identical in the two classes of tardigrades. In addition, the terminology for some of the body parts of the animals varies. I've described some general features of the phylum below.

The body of a tardigrade is long, segmented, and often plump. It has eight short legs that end in curved claws. Three pairs of legs are located under the animal's body and the fourth pair extends from the end. The first three pairs of legs are used to move the animal over the solid components of its environment. The back legs are used to grasp hold of objects.

A tardigrade has a circular mouth. Its eye spots enable it to distinguish light from dark but don't allow it to see an image. The animal may have a distinct color due to pigments in the cuticle or to the contents of the digestive tract. It may be almost colorless, yellow, orange, brown, green, red, or multicolored.

Internal Anatomy and Physiology

Feeding and Digestion

A tardigrade's mouth contains two sharp, rod-like structures called stylets. These are used to pierce plant and animal tissue and suck up the contents. Nematodes (roundworms) seem to be a favorite prey of some tardigrades.

A sucking pharynx pulls the food into the digestive tract from the stylets. The pharynx leads to the esophagus. The remaining sections of the digestive tract are often referred to as the stomach, the intestine, and the rectum. Sometimes the word "gut" is used instead. Indigestible food is eliminated from the body via an opening at the end of the rectum. Food is digested, or broken up, as it travels along the gut, and nutrients are absorbed into the body.

Excretion

Malpighian tubules are connected to the digestive tract. They are thought to act as excretory organs, but the details of their behavior haven't been discovered yet. Excretion is the removal of metabolic waste products from an animal.

Circulation and Respiration

A tardigrade contains unpigmented hemolymph instead of blood. It doesn't have a heart or blood vessels. The hemolymph is spread through the body. The animal is small enough to enable the fluid to circulate during body movement.

Tardigrades lack a special respiratory system. Oxygen diffuses into the hemolymph through the cuticle and carbon dioxide moves in the opposite direction.

Nervous System and Muscles

The animal has a brain in its head, which is connected to a ventral (lower body) double nerve cord. The "brain" has a simpler structure from ours. It's made of fused ganglia. A ganglion is a concentration of neuron cell bodies. The cell body of a neuron (the biological name for a nerve cell) contains the nucleus. Ganglia are also located along the double nerve cord.

A tardigrade doesn't have bones, but it does have muscles. These are attached to the inside of the cuticle and enable the animal to move effectively.

Reproduction

The single reproductive organ is located above the digestive tract. The genders are sometimes separate. The female's ovary produces eggs. These are large structures and are often visible from outside the body. The male's testis produces sperm. Sperm is transferred from the male to the female during mating. The female lays the fertilized eggs and leaves them to hatch. In some species, the female sheds her old cuticle with the eggs inside.

Some tardigrade species are hermaphrodites and produce both eggs and sperm. In other species, parthenogenesis occurs (creation of a new individual from an unfertilized egg).

Lifespan

Tardigrades aren't immortal. As is the case for other animals, they eventually die. "Eventually" may be a very long time, however, depending on an animal's experiences during its life. The lifespan of tardigrades when they don't face environmental stress seems to be quite short. It's believed to be less than a year and may be only a few months. On the other hand, under certain conditions, they may live for decades in an inactive state known as a tun.

The maximum time that the animals can exist in the tun form is still unknown. A few animals have survived for thirty years in this state. Some researchers have speculated that the animals may be able to survive as a tun for a hundred years, though the evidence for this idea seems to be weak at the moment.

The creature loses up to 97 percent of its body moisture and shrivels into a structure about one-third its original size, called a tun.

— William Randoph Miller, via American Scientist

Cryptobiosis in Tardigrades

Cryptobiosis is very important for enabling tardigrades to survive a stress. It's a state in which no metabolic processes can be observed in an animal. The state resembles death, yet the animal is still alive. The body processes that lead to cryptobiosis are reversible, and metabolism begins again when conditions are satisfactory.

Three types of cryptobiosis that have been observed in tardigrades have been given special names.

  • Anhydrobiosis is caused by loss of water.
  • Cryobioisis is caused by freezing conditions.
  • Osmobiosis is caused by extreme salinity.

In each type of cryptobiosis, the tardigrade shrivels up to form a tun. The process is shown in a sped-up view in the video below. In real life, the process is much slower. In experiments, researchers have discovered that once it has become a tun, the animal is resistant to additional stresses, including intense radiation, extreme increase and decrease in temperature, very high pressure, and a vacuum.

Strong radiation is known to damage DNA, which is the genetic material of tardigrades and us. The return to normality in tardigrades after exposure to experimental radiation suggests that the animals have potent DNA repair mechanisms.

The species that live in permanently wet environments such as large bodies of water don't appear to be especially resilient to dehydration. The situation is different for the species that live in an environment that may periodically dry out. They have the amazing ability to lose most of their body water, shrivel up, and still remain alive.

Temperature and Pressure Extremes

It's important to note that not all tardigrade species may be able to survive the stresses described below. In addition, other conditions may need to exist in the animals in order for them to be able to stay alive, such as being in the tun state. A further point to note is that only some of the animals in an experimental group survived. Nevertheless, the results of the experiments are amazing.

According to Dr. William Randolph Miller, a biologist and tardigrade researcher at Baker University in Kansas, at least some species of tardigrades and at least some animals have survived the following extreme conditions in experiments.

  • -272.95 degrees Celsius for twenty hours (Absolute zero is -273.15 degrees Celsius)
  • 150 degrees Celsius (for an unspecified time)
  • -200 degrees Celsius for twenty months
  • 40,000 kilopascals of pressure and 6,000 atmospheres (for an unspecified time in each case)
  • an "excessive" concentration of carbon monoxide, carbon dioxide, sulfur dioxide, and nitrogen
  • a complete vacuum

Many questions exist in relation to how the animals withstand the stresses listed above. For example, at low temperatures, how do their bodies prevent the formation of ice crystals that would damage cells? It's suspected that their cells contain chemicals that act as cryoprotectants and prevent ice formation.

Tardigrades in Space

A Deliberate Experiment

In 2007, a spaceship containing tardigrades was launched. While in space, the box containing the animals was opened, exposing 3,000 animals to the outer environment for twelve days under varying conditions. At the end of this time period, the box was closed and the spaceship returned to Earth.

The researchers found that the animals exposed to a vacuum but not solar radiation survived and seemed to develop no problems as a result of their experience. Exposure to a vacuum plus solar radiation was more challenging for the animals. Many died, but some individuals did survive the stresses.

Some tardigrade species have survived exposure to ultraviolet light on Earth, as described below. Tardigrades have also been exposed to intense x-rays on Earth and survived.

An Accidental Experiment

In April 2019, a spacecraft crashed into the moon. The craft contained tardigrades in a dehydrated form. Researchers say that it should be no problem for any animals that survived the crash to stay alive on the moon, as long as they were in the tun state when they arrived. (Animals that aren't in this state can be killed easily.) The scientists also say that it's highly unlikely that the tuns on the moon will be rehydrated, however, due to the lack of water.

Though the moon does have a thin atmosphere that contains some water, there's not enough present for rehydrating tardigrades. There may well be life on the moon now due to the presence of living tardigrades, but it's almost certainly dormant life, scientists say. Even if the animals were able to rehydrate, they wouldn't be able to find food.

Fluorescent Tardigrades

Scientists recently discovered an interesting mechanism by which one tardigrade species may survive UV radiation exposure. Some researchers in India found a new species of tardigrade growing in moss on a concrete wall. The animal is currently known as Paramicrobiotus BLR. The researchers decided to see how resistant it was to radiation. They found that it survived a fifteen-minute exposure to "germicidal" levels of ultraviolet radiation for thirty days. The exposure killed a tardigrade named Hypsibius exemplaris within twenty-four hours.

The researchers also made another discovery. While they were studying the two tardigrade species under ultraviolet light, they noticed that the test tubes of Paramicrobiotus were glowing due to fluorescence and the Hypsibius tubes weren't. They suspected that the substance or substances producing the fluorescence might be responsible for the protection from ultraviolet radiation.

The researchers ground up members of the first species and created a liquid. They then added the liquid to a dish contain the second species of tardigrade. The animals in the second species had significantly higher survival rates after UV exposure than they did without the presence of the liquid, though they didn't survive as long as the first species. At the moment, the researchers don't know the identity of the protective chemical or chemicals in Paramicrobiotus BLR.

A dorsal or top view of a tardigrade (unknown species)

A dorsal or top view of a tardigrade (unknown species)

Secrets and Future Discoveries

Tardigrades are fascinating and very unusual animals. They may have more secrets to reveal. Many species exist, and relatively few of them have been studied in detail. It's unlikely that every tardigrade species responds in the same way to the stresses that researchers have applied in experiments or even to conditions that they may encounter naturally. The observations obtained so far are tantalizing.

The animals may have a lot to teach us. Despite the claims by some publications, they aren't indestructible. Certain species do seem to be amazingly resilient to some extreme stresses, however. Some scientists suspect that studying the processes that occur in tardigrades as they respond to these stresses may provide benefits for us. Even if this isn't the case, learning more about the amazing abilities of the animals should be very interesting.

References

  • A description of tardigrades from American Scientist (Article written by Dr. William Randolph Miller)
  • Facts about the organs of the animals from "Ask a Biologist" at Arizona State University
  • Information about tardigrades (including information from scientists investigating the animals) from Popular Mechanics
  • Tardigrades in space from the Current Biology journal
  • Resilient animals from Gizmodo
  • Tardigrades return from the "dead" from BBC Earth
  • Tardigrades on the moon from earthsky.org
  • The fluorescent shield of one species from CNN

This content is accurate and true to the best of the author’s knowledge and is not meant to substitute for formal and individualized advice from a qualified professional.

© 2020 Linda Crampton
